QubicaAMF XLi EDGE Pinspotter

Section 4-6 Page 4.6-36 Rev. Date: 10/2016

4.6.7 Pin Deck Light Troubleshooting

4.6.7.1 PROBLEM: Pin Deck Light will not turn on.

Figure 4.6-35

START

YES

Defective LED

fixture?

Replace fixture.

Defective chassis?

Replace chassis.

YES

Is Technician’s Handheld

UnitTHU connected to XLi

Handheld Splitter

Disconnect THU.

YES

Defective cable(s)?

Check/Replace cable(s).

YES

Unplugged/Defective

Dimmer 2 unit?

Check plug or replace

Dimmer 2 unit.

YES

Defective XLi

Handheld Splitter?

Replace XLi Handheld Splitter.
