Section 4.1.
Service Tools
400-088-120-02 Page 4.1-5 Rev. Date: 10/2016
4.1.3 Clipper Belt Lacer (Distributor Belt)
The clipper belt lacer is provided to help the mechanic manufacture replacement
distributor belts. The optimum belt length can vary slightly from distributor to
distributor. If possible, match the existing belt length. The belt lacing will add
approximately 1/4 inch to the overall, installed belt length. Laced belts are also
available from QubicaAMF. To make a belt, refer to the XLi EDGE Pinspotter Pin
Distributor Manual, 400-088-121.
