4.6.5 Chassis Troubleshooting
4.6.5.1 PROBLEM: Table time delay too long or too short.
Figure 4.6-26
START
Scoring enabling
from MCU set
incorrectly?
Set scoring correctly
form MCU.
Defective scoring
cable?
Replace scoring
cable.
Defective chassis?
Replace chassis.
NO
NO
YES
YES
YES
