QubicaAMF XLi EDGE Pinspotter
Section 4.5 Page 4.5-2 Rev. Date: 10/2016
4.5.2 Service the Sweep Assembly
1. Remove power from the pinspotter. Follow appropriate Lock out/Tag out procedures. The Sweep
will have to be cranked to the various positions to allow access to all areas.
2. Wipe the Sweep bar, links, and arms with a cloth sprayed with WD-40.
3. Check for broken, bent, worn, or loose parts or hardware. Tighten, repair, or replace as necessary.
4. Visually inspect the corners of the Sweep Mounts for cracks. Replace if cracks are found.
5. Apply required lubrication following the lubrication schedule.
6. Restore power to the pinspotter, and return the Sweep to the Home position.
7. Cycle the pinspotter. Check the Sweep for operational issues. Make adjustments as necessary
following the applicable procedures in this Service Manual.
4.5.3 Service the Cushion Assembly
1. Remove power from the pinspotter. Follow the appropriate Lock out/Tag out procedures.
2. Check for loose hardware at the Cushion Tube Weldment to Cushion Plank, Box Support to
Kickback Plate, and Hanger Ear to Cushion Tube Weldment.
3. Check pad placement (should straddle Cushion Tube Weldment Upright - ball door side).
4. Check for broken, bent, worn, or loose parts or hardware. Tighten, repair, or replace as necessary.
4.5.4 Service the Distributor Clutch Assembly
Refer to the XLi EDGE Distributor Manual for information relating to this maintenance activity.
4.5.5 Service the Shuttle Assembly
1. Lower the table to respot height.
2. Remove power from the pinspotter. Follow the appropriate Lock out/Tag out procedures.
3. Remove the Shuttle Tension Spring.
4. Remove the Shuttle out of one of the slides on one side by loosening the two bolts and nuts
holding the slide bracket to the rear frame of the Durabin, and then pop the Shuttle out of the
slide. Lower the Shuttle. This provides easier access to the hardware on the Shuttle.
