QubicaAMF XLi EDGE Series User Manual

Preventive Maintenance
400-088-120-02 Page 4.4-87 Rev. Date: 10/2016
Section 4.4
Pinspotter
Every 25,000 Frames
Clean the PBL Assembly & Uprail Assembly – check for loose hardware
Clean the Ball Door Exit, Lift Arm, and LBS Paddle, – check for loose
hardware
Clean the EDGE Performance Lift Inner & Outer Shells, Plows, Flight Cups,
Tabs, & Carrier Rails with diluted AP3 Cleaner, then apply a vinyl type
dressing
Clean the Pit Conveyor Belt
Service the Table Assembly (see subsection 4.5.1)
Service the Sweep Assembly (see subsection 4.5.2)
Service the Cushion Assembly (see subsection 4.5.3)
Service the Distributor Clutch Assembly (refer to the XLi EDGE Distributor
Manual)
Service the Shuttle Assembly (see subsection 4.5.5)
Complete 25,000 Frame Scheduled Lubrication (refer to Section 4.3)
