4.6.5.2 PROBLEM: Sweep time delay too long or too short.
Figure 4.6-27
START
NO
NO
NO
Chassis Pin Data
Delay set incorrectly?
Set pin data delay
correctly.
YES
Defective scoring
cable?
Replace scoring
cable.
YES
Defective chassis?
Replace chassis.
YES
Chassis Start Signal
Delay set incorrectly?
Set start delay correctly.
YES
Defective camera?
Repair or replace
camera.
YES
NO
