Section 4.2
Machine Adjustments
400-088-120-02 4.2-27 Rev. Date: 10/2016
Because of slight variations between lanes and pinspotter adjustments, it may be necessary to fine
tune the position of the Sweep at the 1
st
and 2
nd
Guard positions. This is done by changing the
setpoints in the Guard Set Menu on the Chassis. Refer to the XLi Chassis Manual for specifics on
changing Chassis setpoints. Following a setpoint change, cycle the pinspotter several times until it
is stopping consistently in the same place before making further adjustment.
4.2.3.5 Sweep Motor and Gearbox Removal
For sweep drive motor and gearbox removal, refer to the XLi Motor & Gearbox Manual, P/N 400-
088-038.
