QubicaAMF XLi EDGE Series User Manual

QubicaAMF XLi EDGE Pinspotter
Section 4.4 Page 4.4-88 Rev. Date: 10/2016
Pinspotter
Every 100,000 Frames
Clean the Machine Framework with a water-based cleaner.
Check all Machine Belts for wear and cracking, replace as needed.
Check and tighten Front End Unistrut Jackscrew Jam Nuts.
Check for missing Back End Jackscrew Locks.
Check alignment of Spot/Respot Cam to Spot/Respot Levers (see
subsection 4.5.6)
Check centering of Sweep and Table Home Sensor Disc (see subsection
4.5.7)
Check the Sweep Home Stopping Position (see subsection 4.5.8)
Check the Table Home Stopping Position (see subsection 4.5.9)
Check LBS operation (refer to the Positive Ball Lift (PBL) Manual)
100,000 frame schedule continued on next page
