4.6.3.2 PROBLEM: Sweep overruns all stopping positions. Motor coasts.
Figure 4.6-11
NO
START
Faulty encoder?
Replace encoder.
YES
Defective
chassis?
Replace chassis.
YES
NO
NO
Motor defective?
Replace motor.
YES
Defective motor
brake?
Replace brake.
YES
