QubicaAMF XLi EDGE Series User Manual

QubicaAMF XLi EDGE Pinspotter
Section 4-6 Page 4.6-10 Rev. Date: 10/2016
4.6.2.9 PROBLEM: 2
nd
Ball or Strike – Table runs but does not shuttle
pins or go all the way down to the spotting position.
Figure 4.6.9
YES
No power to spot
solenoid?
Replace fuse in chassis per
Fuse Protection Section in
the Chassis Manual.
Check solenoid wires with
continuity tester. Repair if
defective.
NO
YES
Spot solenoid
defective?
Replace solenoid.
NO
YES
Spot solenoid
binding or out of
adjustment?
Repair or replace
defective parts.
START
NO
YES
Spot solenoid
linkage binding or
broken?
Repair or replace
defective parts.
