QubicaAMF XLi EDGE Series User Manual

Troubleshooting
400-088-120-02 Page 4.6-9 Rev. Date: 10/2016
Section 4.6
4.6.2.8 PROBLEM: Pin fell over during spotting.
Figure 4.6-8
Increase width of
opening with respot
gauge (070-006-519).
YES
Spotting cup end
spacing too narrow?
Replace pin.
YES
Chipped or badly
worn pin base?
NO
START
Clean or replace
defective liner.
YES
Spotting cup
liner is sticky?
NO
NO
Repair cup.
YES
Spotting cup
loose?
Replace cup.
YES
Spotting cup bent
out of shape?
NO
NO
Replace necessary
parts.
YES
Excessive wear in
spotting linkage?
NO
Adjust per
Section 4.
YES
Yoke out of
adjustment?
NO
Adjust spotting
rod.
YES
Spotting rod out of
adjustment?
