4.6.2.7 PROBLEM: 1st ball - sweep starts toward pit, table starts up
with pins in fingers, both stop, neither will run.
Figure 4.6-7
START
Replace
chassis.
YES
Chassis
defective?
NO
NO
Ball detector
mounted inside
path of sweep?
Verify ball detector setting on chassis is
“Behind Sweep”.
YES
Trouble light on
chassis is ON?
Check chassis and correct problem.
Press reset button.
YES
