Troubleshooting
400-088-120-02 Page 4.6-7 Rev. Date: 10/2016
Section 4.6
4.6.2.6 PROBLEM: 1
st
ball - sweep moves down to the guard position,
and the table continues to run.
Figure 4.6-6
START
NO
Table encoder
counts not
changing?
Verify encoder cable is plugged in.
Replace defective encoder.
YES
Defective
chassis?
Replace
chassis.
YES
