400-088-120-02 Page 4.6-23 Rev. Date: 10/2016

Section 4.6

4.6.4.2 PROBLEM: Ball idles at exit – will not enter lift.

Figure 4.6-22

Check mounting

bolts and vibration

dampener. Repair or

replace as needed.

START

Ball lift too low?

Lift arm assembly not

centered between side

plates?

Rudder jammed?

Interference caused

by bounce plate?

Bounce plate

support bracket

loose or broken?

Adjust bumper.

Adjust lift arm.

Adjust rudder.

Repair or replace.

YES

Light ball sensor out

of adjustment?

Adjust per Section 4

of manual.

YES
