QubicaAMF XLi EDGE Pinspotter

Section 4-6 Page 4.6-20 Rev. Date: 10/2016

4.6.3.10 PROBLEM: Sweep runs too far into pit area.

Figure 4.6-19

START

Sweep collapsing

into pit area?

Check box beam

clearance after

adjustment.

Adjust sweep. Refer to

Section 4 for sweep

adjustments.

Shorten sweep

connecting rod

assembly.

YES
