QubicaAMF XLi EDGE Series User Manual

Troubleshooting
400-088-120-02 Page 4.6-19 Rev. Date: 10/2016
Section 4.6
4.6.3.9 PROBLEM: 2
nd
ball or strike – table does not run, bins loaded
with pins but will not drop the pins into the spotting cups.
Figure 4.6-18
Replace chassis.
Defective
chassis?
START
Bin switch lever
defective?
Bin switch
open?
Bin switch
wiring open?
Repair lever.
Check with continuity tester.
Replace switch if defective.
Check with continuity tester.
Repair wiring if defective.
NO
NO
NO
YES
YES
YES
YES
