QubicaAMF XLi EDGE Pinspotter
Section 4.5 Page 4.5-10 Rev. Date: 10/2016
14. Check for loose, worn, or missing hardware. Tighten or replace as needed.
15. Release the spring tension on the Front Bearing Supports using the carpet tool and flag, remove
the Carpet Pins or 1/4-20 bolts and allow the Front Bearing Supports to rotate forward. Use a
spring puller to remove the spring from the stud on the side plate.
16. Remove the snap rings with snap ring pliers and slide the Bearing Supports off the Pivot Studs.
Clean the studs and Bearings Supports.
17. Check the studs for wear. Replace as needed.
18. Check the Bearing Support Bushings. Replace as needed.
19. Check the condition of the rubber support and the metal "ears" that hold the rubber in place.
Replace as needed.
20. Lubricate the Pivot Studs and Bearing Support Bushings with grease.
21. Install the Bearing Supports and retain with the snap rings.
22. Attach the springs to the stud on the side plate using a spring puller. With the carpet tool and flag,
rotate the Front Bearing Supports until a Carpet Pin (792-501-001) or a 7/16-20 x 3/4" bolt can be
inserted into the hole in the side plate to hold the Front Bearing Support under tension.
23. Check the Rubber Supports, Support Retainer, and the Support Weldment that hold the rear roller
in place for excessive wear. Replace as needed.
24. Check the Pit Support Brackets for worn or broken studs or cracking. Replace as needed.
25. Check the condition of the Kickback fiber panels and rivets. Replace as needed.
26. Remove the Pit Conveyor Belt from the Bounce Board.
27. Check the Bounce Boards for cracks and excessively worn or damaged areas. Replace as needed.
28. Check the support channels and angle support for cracks or broken areas. Replace as needed.
29. Check the Vibration Dampeners for deformity or cracks and rips in the rubber. Replace as needed.
30. Check that the Bonding Strap is in good condition. Replace as needed.
31. Remove any belt fabric from the bearing area on the front and rear rollers.
32. Check the condition of the bearings on the front and rear rollers. Replace as needed.
33. Check for excessive play in the Front Roller Assembly halves, or if the front roller was knocking
during operation, replace or rebuild the front roller.
34. Install the Pit Conveyor Belt onto the Bounce Board Assembly. The arrow on the Pit Conveyor Belt
must point in the direction of belt rotation.
