QubicaAMF XLi EDGE Series User Manual

Troubleshooting
400-088-120-02 Page 4.6-3 Rev. Date: 10/2016
Section 4.6
4.6.2.2 PROBLEM: Scoring or Pindication Problems (miscounts, no
strike cycle, etc.)
Figure 4.6-2
YES
Defective camera?
Replace camera.
Defective power
supply?
Replace power supply
transformer.
YES
NO
NO
Scoring problem
only occurs when
black light is on?
YES
Replace infrared LEDs.
YES
Defective camera
cable?
Repair or replace cable.
NO
NO
Machine
interference?
Check for loose
components on the
pinspotter that may be
blocking the camera’s view.
YES
START
NO
Camera out of
adjustment?
Adjust camera.
YES
