QubicaAMF XLi EDGE Pinspotter

Section 4-6 Page 4.6-14 Rev. Date: 10/2016

4.6.3.4 PROBLEM: Sweep hits gutter at 66 guard position.

Figure 4.6-13

Adjust sweep

mounting bolts

Replace shock

mounts.

START

Rubber

bumper

worn?

Shock

mounts

broken?

Sweep bar

out of

alignment?

Sweep link bracket

out of adjustment or

bolt loose?

Replace worn

bumper.

Adjust and

tighten link.
