QubicaAMF XLi EDGE Series User Manual

400-088-120-02  2016 QubicaAMF Worldwide Page
Rev. Date: 10/2016
5-55
ITEM
QTY
PART #
DESCRIPTION
ITEM
QTY
PART #
DESCRIPTION
1
1
088-001-593
KICKPLATE, 10-PIN SIDE,, ODD MACHINE
32
1
000-029-602
BRACKET WELDMENT, 10-PIN SIDE, ODD
2
1
088-001-592
KICKPLATE, 7-PIN SIDE,, EVEN MACHINE
MACHINE
3
1
000-022-794
BLOCK SUPPORT, 10-PIN SIDE
32A
1
000-029-672
BEARING BRACKET ASSEMBLY, 10-PIN SIDE
4
1
000-022-795
BLOCK SUPPORT, 7-PIN SIDE
ODD MACHINE (Includes 17, 31, 32, & 34)
5
1
000-022-300
SHIELD
33
1
000-022-248
BRACKET WELDMENT 7-PIN SIDE, EVEN
6
1
000-022-788
BOX SUPPORT
MACHINE
7
3
951-164-002
WASHER, SPLIT LOCK, 3/8
33A
1
000-022-249
BEARING BRACKET ASSEMBLY, 10-PIN SIDE
8
5
809-865-165
SCREW, HEX, 3/8 - 16 X 1
EVEN MACHINE (Includes 17, 31, 33, & 34)
9
1
809-865-645
SCREW, HEX, 3/8 - 16 X 4
34
1
710-501-009
GREASE FITTING
10
3
844-065-002
NUT, STOVER LOCK, 3/8 - 16
35
1
000-027-641
THRUST BEARING
11
2
000-024-890
SETSCREW
36
1
000-029-015
PIVOT STUD
12
1
088-001-567
ANTI-IDLING CORNER, ODD
37
1
948-975-172
WASHER, FLAT, 1 X 1/2 X 1/16
13
1
088-001-568
ANTI-IDLING CORNER, EVEN
38
1
844-074-002
NUT, STOVER LOCK, 1/2 - 20
14
2
808-857-160
SCREW, FLAT HEAD, 5/16-18 X 1
39
6
808-857-120
SCREW, FLAT HEAD, 5/16 - 18 X 3/4
15
2
090-004-136
SPACER
40
1
000-024-668
TRACK SUPPORT BRACKET
16
1
000-022-926
RETAINER SUPPORT
41
2
809-865-145
SCREW, HEX, 3/8-16 X 7/8
17
2
000-022-924
BEARING SUPPORT
18
4
808-557-120
SCREW, BUTTON HEAD, 5/16 - 18 X 3/4
43
1
000-028-362
BUMPER, URETHANE
19
8
844-057-002
NUT, FLEX LOCK, 5/16 - 24
44
1
070-011-642
URETHANE DOOR RING, ODD MACHINE, 10-PIN SIDE
20
1
088-001-569
ANTI-IDLING CHANNEL WELDMENT, ODD
45
1
070-011-641
URETHANE DOOR RING, EVEN MACHINE, 7-PIN SIDE
21
1
088-001-570
ANTI-IDLING CHANNEL WELDMENT, EVEN
46
1
070-004-642
BALL LIFT STOP BRACKET
22
1
088-001-583
ANTI-IDLING NOISE PAD
47
1
000-024-641
STOP BUMPER
23
4
000-026-865
FLAT WASHEER, 3/8 X 7/8 X 1/16
48
5
809-857-125
SCREW, HEX, 5/16 - 18 X 3/4
24
4
808-849-160
SCREW, FLAT HEAD, ¼-20 X 1
49
1
835-558-002
NUT, HEX JAM, 5/16 - 24
25
6
844-049-002
NUT, STOVER LOCK, 1/4 - 20
50
1
088-500-190
CURTAIN ROD BUSHING, CS
26
1
090-004-131
PIT SUPPORT BRACKET
51
2
088-849-120
SCREW, BUTTON HEAD, 1/4 - 20 X ¾
27
2
948-767-132
WASHER, 13/32 X 13/16 X 1/16
52
1
088-001-034
SINGLE SADDLE BRACKET WELDMENT
28
1
000-021-204
SPRING
53
1
000-029-640
KICKBACK PANEL
29
1
919-005-800
RETAINING RING
54
7
938-101-015
PLASTIC RIVET 1/4 BLACK
30
1
000-027-642
FRONT ROLLER SUPPORT WASHER
n/a
1
008-100-413
ADHESIVE (apply between items 3&5 or 4&5
31
1
900-112-203
SLEEVE BEARING, .753 X 1-1/4
as applicable)
55
3
808-957-160
5/16-18 x 1 Screw, Flat Head – Nylon Patch
56
1
808-957-120
5/16-18 x ¾ Screw, Flat Head – Nylon Patch
* KICKBACK PLATE ASSEMBLY– BALL EXIT SIDE
