QubicaAMF XLi EDGE Series User Manual

400-088-120-02  2016 QubicaAMF Worldwide Page
Rev. Date: 10/2016
5-57
ITEM
QTY
PART #
DESCRIPTION
ITEM
QTY
PART #
DESCRIPTION
1
1
088-001-594
KICKBACK WELDMENT 10-PIN SIDE,
33
1
000-022-794
BLOCK SUPPORT, 10-PIN SIDE
EVEN MACHINE
34
1
000-022-795
BLOCK SUPPORT, 7-PIN SIDE
2
1
088-001-591
KICKBACK WELDMENT 7-PIN SIDE,
35
1
000-022-300
SHIELD
ODD MACHINE
36
1
809-865-645
SCREW, HEX, 3/8 - 16 X 4
3
1
000-029-015
PIVOT STUD
37
1
000-021-044
BRACKET WELDMENT, 10-PIN SIDE, EVEN
4
1
000-027-641
THRUST BEARING
MACHINE
5
1
000-027-642
FLAT WASHER, .75 X 1¼ X .0478
37A
1
000-027-646
BEARING ASSEMBLY., 10-PIN SIDE, EVEN
6
1
919-005-800
RETAINING RING
MACHINE (includes: 14, 37, 39 & 40)
7
1
000-021-204
SPRING
38
1
000-021-043
BRACKET WELDMENT, 7-PIN SIDE, ODD
8
1
090-004-131
PIT SUPPORT BRACKET
MACHINE
9
2
000-024-890
SETSCREW (JACK SCREW)
38A
1
000-027-645
BEARING ASSEMBLY., 7-PIN SIDE, ODD
10
1
000-023-468
BRACKET
MACHINE (includes: 14, 38, 39 & 40)
11
1
000-022-878
ANGLE
39
1
710-501-009
GREASE FITTING
12
1
000-023-465
SUPPORT WELDMENT, EVEN MACHINE
40
1
900-112-203
SLEEVE BEARING, .753 X 1-1/4
13
1
000-023-464
SUPPORT WELDMENT, ODD MACHINE
n/a
1
008-100-413
ADHESIVE apply between items (33&35 or
14
2
000-022-924
BEARING SUPPORT
34&35as applicable)
15
1
000-023-467
FLANGED BEARING, .314 X .434 X .310
16
1
070-002-027
KICKBACK PANEL
17
2
809-849-125
SCREW, HEX,¼ - 20 X ¾
18
2
844-049-002
NUT, STOVER LOCK, ¼ - 20
19
2
809-857-125
SCREW, HEX, 5/16 - 18 X ¾
20
1
809-857-165
SCREW HEX, 5/16 - 18 X 1
21
3
844-057-002
NUT, STOVER LOCK, 5/16 - 18
22
5
809-865-165
SCREW, HEX, 3/8 - 16 X 1
23
3
844-065-002
NUT, STOVER LOCK, 3/8 - 16
24
3
951-164-002
WASHER, SPLIT LOCK, 3/8
25
2
948-767-132
WASHER
26
1
948-975-172
WASHER, FLAT, .53 x 1.06 x .10
27
1
844-074-002
NUT, STOVER LOCK, 1/2 - 20
28
9
938-101-015
PLASTIC RIVET 1/4 BLACK
29
1
000-026-464
KICKBACK BRACKET
30
1
709-013-059
SCREWBOLT, HEX, 8 mm X 75 mm
31
1
937-738-003
RIVET, STEEL
32
1
000-022-788
BOX SUPPORT
* KICKBACK PLATE ASSEMBLY– SIDE OPPOSITE BALL EXIT
