QubicaAMF XLi EDGE Series User Manual

400-088-120-02  2016 QubicaAMF Worldwide Page
Rev. Date: 10/2016
5-61
ITEM
QTY
PART #
DESCRIPTION
ITEM
QTY
PART #
DESCRIPTION
1
1
070-002-252, -050
CUSHION TUBE WELDMENT
26
1
000-022-823
SHOCK ABSORBER w/UPPER COLLAR
2
1
000-024-795, -796
CUSHION PLANK
26A
1
000-022-824
SHOCK ASSY (Includes items 26 through 32)
3
4
951-164-002
SWM 3/8 ANSI NS
27
1
000-022-286
CUSHION STRUT COLLAR
4
1
000-002-770
CUSHION ASSEMBLY SPONGE PAD
28
1
000-022-288
SPRING
5
1
070-002-176
PIN CURTAIN DETAIL
29
1
000-022-287
SPRING SEATING WASHER
6
1
000-024-808, -807
CUSHION RUBBER
30
1
810-250-200
SCREW, SOCKET HEAD CAP, ¼ - 28 X 1-1/4
7
1
090-005-230
CUSHION COVER
31
1
951-148-002
WASHER, SPLIT LOCK, ¼
8
16
000-028-529
CUSHION ASSEMBLY RIVET
32
2
000-022-822
SLEEVE
9
1
070-011-288
CUSHION ASSEMBLY CURTAIN ROD
33
4
948-975-172
WASHER, FLAT, 1-1/16 X 17/32 X 3/32
10
2
913-437-240
PIN RL 0.19 X 1.50 NS
34
2
000-022-821
PIN
11
4
000-021-792
FW 0.41 X 0.88 X 0.13 BO
35
4
963-600-002
X-WASHER
12
2
945-091-242
FW 1.02 X 1.50 X 0.05 ZN
36
1
070-007-360
SUPPORT BRACKET WELDMENT
13
1
070-005-610
CUSHION ASSEMBLY LINK
37
1
070-001-389
CURTAIN LATCH SPRING
14
1
000-024-534
CUSHION ASSEMBLY EAR HANGER
38
1
070-001-396
CURTAIN LATCH PIN
15
2
809-857-125
HHCS 5/16-18 X 0.75 GR8 PB
39
1
913-431-160
SPRING PIN, .156 X 1
16
6
844-057-002
HLN 5/16-18 CAD STV
17
1
070-001-432
CUSHION ASSEMBLY PAD
18
2
070-001-422
CUSHION ASSEMBLY U BOLT
19
2
070-001-421
CUSHION ASSEMBLY STRAP
20
2
947-356-617
FW 5/16 USS ZY
21
2
809-865-285
HHCS 3/8-16 X 1.75 GR8 PB
22
2
809-865-365
HHCS 3/8-16 X 2.25 GR8 PB
23
12
7023-410800-100
PHPPS 8 X 1.00 ZN
24
4
000-024-750
CUSHION MOUNT WELDNUT
* CUSHION, CURTAIN, & SHOCK ABSORBER ASSEMBLY
