QubicaAMF XLi EDGE Series User Manual

XLi EDGE Pinspotter
Section 4-1 Page 4.1-2 Rev. Date: 10/2016
Table 4.1-1a, Deluxe Tool Kit Parts List
ITEM
PART#
DESCRIPTION
ITEM
PART#
DESCRIPTION
1
788-504-004
12" Hacksaw
34
789-006-008
4” Flat Blade Screwdriver
2
789-512-029
Universal 3/8" Drive
35
789-001-001
2” #2 Phillips Screwdriver
3
789-512-028
Universal 1/4" Drive
36
793-507-030
11/16 X 3/4" Offset Box Wrench
4
782-501-001
12" Extension 3/8" Drive
37
793-507-029
9/16" X 5/8" Offset Box Wrench
5
789-502-004
6" Extension 3/8" Drive
38
793-507-028
7/16" X 1/2" Offset Box Wrench
6
789-502-003
3" Extension 3/8" Drive
39
793-510-044
3/4" X 7/8" Ratching Box Wrench
7
792-005-005
Tool Box
40
793-510-043
5/8" X 11/16" Ratching Box Wrench
8
793-503-017
Hex Key Set
41
793-510-042
1/2" X 9/16" Ratching Box Wrench
9
793-002-007
Snap Ring Pliers
42
793-510-041
3/8" X 7/16" Ratching Box Wrench
10
793-503-051
Hex Key Set (14 Pieces)
43
792-517-037
9” Torpedo Level (not shown)
11
792-512-019
Crimping Tool
44
789-509-030
1/2" Deep Socket, 3/8" Dr
12
786-501-001
10" Channelock
®
Pliers
45
deleted
13
793-514-048
10" Vise Grip
®
Pliers
46
789-509-022
3/4" Deep Socket, 3/8" Dr
14
786-503-003
6" Slip Joint Pliers
47
789-509-021
11/16" Deep Socket, 3/8" Dr
15
786-502-002
6" Needle Nose Pliers
48
789-509-020
5/8" Deep Socket, 3/8" Dr
16
786-504-004
6" Diagonal Cutters
49
789-509-019
9/16" Deep Socket, 3/8" Dr
17
792-029-031
Wire Strippers
50
789-509-018
7/16" Deep Socket, 3/8" Dr
18
714-501-001
Padlock
51
789-505-008
3/8" Drive Rachet
19
789-511-027
1/4" Drive Socket Set (13 Pieces)
52
780-503-014
3/8" Drive Hex Bit Set (6 Pieces)
20
793-506-050
3/4" Combination Wrench
53
deleted
21
793-506-027
11/16" Combination Wrench
54
792-026-028
1/2" X 8' Steel Tape Measure
22
793-506-026
5/8" Combination Wrench
55
793-501-003
10" Adjustable Wrench
23
793-506-025
9/16" Combination Wrench
56
793-501-002
8" Adjustable Wrench
24
793-506-024
1/2" Combination Wrench
57
793-501-001
6" Adjustable Wrench
25
793-506-023
7/16" Combination Wrench
58
787-001-006
Punch Set (6 Pieces)
26
793-506-022
3/8" Combination Wrench
59
791-004-004
Testlight - 80V - 600V
27
793-506-021
5/16" Combination Wrench
60
783-502-002
Mallet - 16 oz. Plastic
28
793-505-020
15/16" Combination Wrench
61
783-501-001
Hammer - 16 oz. Ball Peen
deleted
62
deleted
deleted
63
792-020-044
12" Combination Square
31
088-000-210
Mini-Fit Pin Crimp Tool (not shown)
64
793-513-048
Torque Wrench, 250 in-lb
32
789-006-009
8" Flat Blade Screwdriver
65
780-503-015
4mm Allen Hex 3/8” Socket
33
789-001-002
4" # 2 Phillips Screwdriver
