XLi EDGE Pinspotter
Section 4-2 4.2-36 Rev. Date: 10/2016
6. Place the free end of the grounding strap over the stud at the right rear vibration dampener
and install the washers and 5/16-inch lock nuts onto the studs at each corner of the bounce
plate assembly. Tighten securely. Make sure that the pin conveyor belt is free and not
pinched between the bounce board and brackets.
7. Install the front roller by passing it through the ball exit opening of the adjacent machine and
into the belt on top of the bounce board, but do not position in the bearing supports yet.
8. Before the front roller can be replaced, spring tension must be applied to the bearing support
assemblies.
Keep your fingers clear of any moveable parts while applying spring
tension. A severe pinching hazard exists.
a. Place the flag on the belt installation tool, and hook the tool on the bearing support
assembly as shown in Figure 4.2-36.
b. Apply pressure toward the rear of the machine until the bearing support bracket clears the
hole in the kickback plate, and insert the retaining pin into the hole. The belt installation
tool can be rotated in the flag while applying pressure in order to provide additional
clearance.
c. Repeat steps 8a and 8b for the other side of the machine.
d. Install the front roller in the bearing supports.
e. Grasp the end of the roller assembly on the top only and roll it into the support assembly.
Repeat for the other end of the roller. Make sure that the roller bearings are fully seated
in the bearing supports.
f. Apply pressure at one end of the front roller with the belt installation tool and remove the
retaining pin. Carefully ease off on the roller. Repeat for the other end of the roller.
9. Reinstall the paddle on the rudder arm.
10. Install the EDGE Performance Lift. Refer to the EDGE Performance Lift PSP Manual
Supplement.
NOTE: Some break-in may be required for certain styles of pin conveyor belts.
