QLS-4100 Xe 5-7
• Indicates that data port-specific commands were received via the status
port, causing a communications error. Ensure that the data port is set up
correctly.
• Displayed when a printhead x is lifted after the printer has been
powered on. Pressing select will disable this head until the printer power
has been cycled. The following message is displayed after a printhead is
disabled:
• Displayed after the self-test when the printer is powered on with one or
more of the heads already lifted. The printer indicates which heads have
been disabled upon power up.
Data Port Error
Check Comm Setup
Printheads Disabled
Hd1 Hd2 Hd3 Hd4
Head x Disabled
Head x up
SELECT to disable
