Instrument Functions
R&S
®
NRP2
158User Manual 1173.9157.02 ─ 03
Firmware
Keybd. Ctrl. Version of the keyboard controller software.
Options Short name of the installed options.
Hardware
Serial No
Serial number of the R&S NRP2.
Stock No R&S material number.
MAC Address Ethernet hardware address.
RAM RAM size.
Flash Flash memory size, holding the operating system, the firmware and the
stored data (non-volatile).
CPU Clock Frequency of the CPU clock.
CPLD Version of the CPLD (Complex Programmable Logic Device).
PIC Version of the keyboard controller
SCPI command:
SYSTem:INFO? on page 318
4.7.5 Miscellaneous
The "Misc" dialog box covers useful parameters for manual measurements, such as the
display update rate or acoustic alarms.
► Select "Misc..." in the "System" menu.
Fig. 4-91: Miscellaneous dialog box
System settings
