<head><meas_mode>[<calc_function>][?] <parameter_list>
Table 6-5: Syntactical Structure of High-Level Measurement Commands
<head>
<head> = These keywords select the high level command subsystem.
Command keywords
●
CONFigure<[1]..8>
●
FETCh<[1]..8>
●
MEASure<[1]..8>
●
READ<[1]..8>
<meas_mode>
<meas_mode> = These keywords select the measurement mode ( ContAv, ContAv
with data buffering, Burst, Timeslot, Trace, or Statistics, see also low lwvwl command
[SENSe<[1]..4>]:FUNCtion[:ON] on page 268).
Command keywords
●
[:SCALar][:POWer][:AVG] (ContAv mode)
●
[:SCALar][:POWer]:TSLot (T'slot mode)
●
[:SCALar][:POWer]:BURSt (Burst mode)
●
:ARRay[:POWer][:AVG] (ContAv with data buffering mode)
●
:XTIMe[:POWer] (Trace mode)
●
:STATistics:CCDF (Statistics mode)
●
:STATistics:PDF Statistics mode)
<calc_function>
<calc_function> = These keywords select the calculation function, see also the low level
commandCALCulate<[1]..8>:MATH[:EXPRession] on page 228). If
<calc_function> is not specified, the measured value of the primary channel is output.
Command keywords
●
:RELative
●
:DIFFerence
●
:DIFFerence:RELative
●
:SUM
●
:SUM:RELative
●
:RATio
●
:RATio:RELative
●
:RLOSs
●
:SWR
●
:REFLection
[?]
The "?" terminates the measurement commands which are always queries. Measure-
ment commands are the FETCh:...?, READ:...? and MEASurement:...? com-
mands.
<param_list>
A list with parameters is sent with the high level command. The meaning of the param-
eters is determined by the <meas_mode>, see chapter 6.4.4, "Parameter list descrip-
tion", on page 210.
6.4.4 Parameter list description
Six different parameter lists are used in the high end measurement commands. Which
list is used depends on the selected measurement mode. The elements of these lists can
be omitted starting at the end and working backward. They will then be replaced by their
default values.
Parameter lists for the different measurement modes
●
measurement mode ContAV:
[<expected_value> [,<resolution>]] [,<source_list>]
●
measurement mode T'slot:
