Remote Control - Commands
R&S
®
NRP2
211User Manual 1173.9157.02 ─ 03
<tslot_width>, <no_slots>, <start_exclude>, <end_exclude>,
[<expected_value> [,<resolution>]] [,<source_list>]
●
measurement mode Burst:
<dtolerance>, <start_exclude>, <end_exclude>, [<expected_value>
[,<resolution>]] [,<source_list>]
●
measurement mode ContAv (with data buffering)
(<buffered_size>), [<expected_value>[,<resolution>]]
[,<source_list>]
●
measurement mode Trace:
(<scope_size>), <capture_time> [,<source_list>]
●
measurement mode Statistics:
(<statistics_size>), <capture_time> [,<source_list>]
The elements of the parameter lists have the following meaning:
Table 6-6: Description of the parameters in the parameter list in alphabetical order
<buffered_size>
Value range: depending on sensor.
Default value: depending on sensor.
Unit: -
Number of requested measured values. Corresponds to command:
[SENSe<[1]..4>][:POWer][:AVG]:BUFFer:SIZE on page 270.
<capture_time>
Value range: depending on sensor.
Unit: S
Default value: depending on sensor.
Period within which measured data are captured in the Trace mode. Corresponds
to command:
[SENSe<[1]..4>]:TRACe:TIME on page 290.
Period within which measured data are captured in the STATistics mode. Corre-
sponds to command:
[SENSe<[1]..4>]:STATistics:TIME on page 281.
<dtolerance>
Value range: depending on sensor.
Unit: S
Default value: depending on sensor.
The length of a time interval in which the power level may drop below the trigger
level without the end of a power pulse being detected. Corresponds to command:
[SENSe<[1]..4>][:POWer]:BURSt:DTOLerance on page 272.
<end_exclude>
Value range: depending on sensor
Default value: depending on sensor
Unit: S
Amount of time at the end of a timeslot or integration period that should not be
taken into account. Corresponds to command:
[SENSe<[1]..4>]:TIMing:EXCLude:STOP on page 281.
High-Level Measurement Commands (CONFigure, MEASure, READ and FETCh)
