[SENSe<[1]..4>]:RGAMma:PHASe <phase_angle>
SENSe:RGAMma:PHASe defines the phase angle (in degrees) of the complex reflection
factor of the load at the signal output.
Parameters:
<phase_angle> float_value
Range: depending on sensor
*RST: depending on sensor
Default unit: only the unit degree is accepted
[
SENSe<[1]..4>]:SAMPling <sampling_rate>
If the signal to be measured has modulation sections just above the video bandwidth of
the sensor used, measurement errors might be caused due to aliasing effects. In this
case, the sampling rate of the sensor can be set to a safe lower value (FREQ2). However,
the measurement time required to obtain noise-free results is extended compared to the
normal sampling rate (FREQ1).
Parameters:
<sampling_rate> FREQ1 | FREQ2
*RST: depending on sensor
[SENSe<[1]..4>]:SGAMma[:MAGNitude] <magnitude>
The R&S NRP2 can perform a measured-value correction taking the complex reflection
coefficient (source gamma) of the signal source into account.
SENS<[1]..4>:SGAM:CORR:STAT ON must be set. The magnitude of the reflection
coefficient is set with SENS<[1]..4>:SGAM[:MAGN].
Parameters:
<magnitude> float_value
Range: depending on sensor
*RST: depending on sensor
[SENSe<[1]..4>]:SGAMma:PHASe <phase>
The R&S NRP2 can perform a measured-value correction taking the complex reflection
coefficient (source gamma) of the signal source into account.
SENS<[1]..4>:SGAM:CORR:STAT ON must be set. The phase angle of the reflection
coefficient is set with SENS<[1]..4>:SGAM:PHAS.
Parameters:
<phase> float_value
Range: depending on sensor
*RST: depending on sensor
Default unit: degree
SENSe (Sensor Commands)
