Table 5.8 Mode Settings for Measurement
Point
Page
1 2 3 4 5 6 7 8
Time Of Specified Range
Measurement
Ο Ο Ο Ο Ο Ο Ο Ο
Start Point To End Point
Measurement
Ο Ο Ο Ο Ο Ο Ο Ο
Start Range To End
Range Measurement
Ο ⎯ Ο ⎯ Ο ⎯ Ο ⎯
Access Count Of
Specified Range
Measurement
Ο ⎯ Ο ⎯ Ο ⎯ Ο ⎯
Called Count Of
Specified Range
Measurement
Ο ⎯ Ο ⎯ Ο ⎯ Ο ⎯
Note: Ο: Available
⎯: Not available
Note: Only one point is used in Time Of Specified Range Measurement and Start Point To End Point
Measurement, while two sequential points are used in Start Range To End Range Measurement, Access
Count Of Specified Range Measurement, and Called Count Of Specified Range Measurement. The
conditions that have been set will be canceled when switching these modes of different types.
