8.2.5 Note on Emulation of the H8/36912 Group and H8/36902 Group
The ROM/RAM capacity for the H8/36911 of the H8/36912 group and the H8/36901 and H8/36900 of the
H8/36902 group is different in the MCU and the emulator. When you create a user program, be careful of the
ROM/RAM usage because the size of the ROM/RAM in the emulator is larger than that of the MCU. In the
MCU, specifying an unused area (addresses) by a range channel of an event point allows the program to stop
when an illegal access occurs. For how to set event points, refer to section 5.15.7, Setting Event Points.
Table 8.57 Differences on the ROM/RAM Capacity
MCU E6000 Emulator
Device Name ROM RAM ROM RAM
H8/36911 4 kbytes 256 bytes 8 kbytes 512 bytes
H8/36901 4 kbytes 256 bytes 8 kbytes 512 bytes
H8/36900 2 kbytes 256 bytes 8 kbytes 512 bytes
