Renesas H8 Series User Manual

40
5.1.2 Selecting an MCU Not Included in the List
Selecting [Custom] in [Device] of the [Configuration Properties] dialog box adds the [Custom Device] page to
the dialog box.
Figure 5.2 [Configuration Properties] Dialog Box ([Custom Device] Page)
Use this page to specify functions for an MCU not included in the list of MCUs. The items are adopted by the
device last selected.
[Custom Device] page
[ROM] Specify the internal ROM area size.
[RAM] Specify the internal RAM area size.
[Pin] Specify the product package.
[Modules] Check this box to validate on-chip peripherals.
Note: The items that can be set in this dialog box vary according to the emulator in use. Some emulators may
not support the [Custom Device] function. For details, refer to section 8, Software Specifications
Specific to This Product, or the online help.
