125
6.6 Executing the Program
Execute the program as described in the following:
• To execute the program, select [Go] from the [Debug] menu, or click the [Go] button on the toolbar.
Figure 6.7 [Go] Button
While the program is executing, the current address bus value and the operating state of the MCU are displayed
on the status bar.
The program will be executed up to the breakpoint that has been inserted, and an arrow will appear on the [S/W
Breakpoints] column in the [Editor] window to show the position that the program has halted, with the message
[Break = Software Break] in the status bar.
Note: When the source file is displayed after a break, a path of the source file may be inquired. The location of
the source file is as follows:
OS installation drive \Workspace\Tutorial\E6000\2646\Source
The directory mentioned above cannot be specified depending on the version of the software. In such
cases, specify the following directory instead.
High-performance Embedded Workshop installation destination directory
\Tools\Renesas\DebugComp\Platform\E6000\2646\Source
The file path differs depending on the product. If necessary, replace \2646 with another name.
