139
6.13 Forced Breaking of Program Executions
The High-performance Embedded Workshop can force a break in the execution of a program.
• Cancel all the breaks.
• To execute the remaining sections of the tutorial function, select [Go] from the [Debug] menu or the
[Go] button on the toolbar.
Figure 6.26 [Go] Button
• The program goes into an endless loop. To force a break in execution, select [Halt] from the [Debug] menu
or the [Stop] button on the toolbar.
Figure 6.27 [Stop] Button
6.14 Resetting the MCU
Resetting the MCU initializes the internal I/O registers and makes the program counter jump to the address set in
the reset vector.
To reset the MCU, select [Reset CPU] from the [Debug] menu or the [Reset CPU] button on the toolbar.
Figure 6.28 [Reset CPU] Button
To execute the program from the reset vector, select [Reset Go] from the [Debug] menu or the [Reset Go] button
on the toolbar.
Figure 6.29 [Reset Go] Button
Note: This tutorial program is executable from the reset vector.
