Table 8.20 Differences between the Evaluation Chip and the H8/3664, H8/3672 Group Products

Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 TXD2 PWM TXD TMOW

H'FFE1 PMR5 POF57 POF56 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0

H'FFE2 PMR3 POF27 POF26 POF25 POF24 POF23 ⎯ ⎯ ⎯

H'FFF1 SYSCR2 SMSEL LSON DTON MA2 MA1 MA0 SA1 SA0

H'FFF2 IEGR1 NMIEG ⎯ ⎯ ⎯ IEG3 IEG2 IEG1 IEG0

H'FFF4 IENR1 IENDT IENTA IENWP ⎯ IEN3 IEN2 IEN1 IEN0

H'FFF5 IENR2 IENTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯

H'FFF9 MSTCR1 MSTS4 MSTIIC MSTS3 MSTAD MSTWD MSTTW MSTTV MSTTA

H'FFFA MSTCR2 MSTS3_2 MSTTB3 MSTTB2 MSTTB1 MSTTX ⎯ MSTTZ0 MSTPWM

H8/3660

(Evalua-

tion chip)

H'FFFB MSTCR3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ MSTS4_2

Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 ⎯ ⎯ TXD TMOW

H'FFE1 PMR5 ⎯ ⎯ WKP5 WKP4 WKP3 WKP2 WKP1 WKP0

H'FFE2 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H'FFF1 SYSCR2 SMSEL LSON DTON MA2 MA1 MA0 SA1 SA0

H'FFF2 IEGR1 NMIEG ⎯ ⎯ ⎯ IEG3 IEG2 IEG1 IEG0

H'FFF4 IENR1 IENDT IENTA IENWP ⎯ IEN3 IEN2 IEN1 IEN0

H'FFF5 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H'FFF9 MSTCR1 ⎯ MSTIIC MSTS3 MSTAD MSTWD MSTTW MSTTV MSTTA

H'FFFA ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H8/3664

H'FFFB ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

H'FFE0 PMR1 IRQ3 ⎯ ⎯ IRQ0 ⎯ ⎯ TXD ⎯

H'FFE1 PMR5 POF57 POF56 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0

H'FFE2 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H'FFF1 SYSCR2 SMSEL ⎯ DTON MA2 MA1 MA0 ⎯ ⎯

H'FFF2 IEGR1 ⎯ ⎯ ⎯ ⎯ IEG3 ⎯ ⎯ IEG0

H'FFF4 IENR1 IENDT ⎯ IENWP ⎯ IEN3 ⎯ ⎯ IEN0

H'FFF5 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H'FFF9 MSTCR1 ⎯ ⎯ MSTS3 MSTAD MSTWD MSTTW MSTTV ⎯

H'FFFA ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯

H8/3672

H'FFFB ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
