212
(e) While emulating the H8/36037, H8/36057 group, set PCR9 to ‘0’ if you want to use TinyHCAN or SSU.
Table 8.38 Differences between the Evaluation Chip and the H8/36037, H8/36057 Registers
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F731 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 TXD2 PWM TXD TMOW
H'FFE1 PMR5 POF57 POF56 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0
H'FFE2 PMR3 POF27 POF26 POF25 POF24 POF23 ⎯ ⎯ ⎯
H'FFF1 SYSCR2 SMSEL LSON DTON MA2 MA1 MA0 SA1 SA0
H'FFF2 IEGR1 NMIEG ⎯ ⎯ ⎯ IEG3 IEG2 IEG1 IEG0
H'FFF4 IENR1 IENDT IENTA IENWP ⎯ IEN3 IEN2 IEN1 IEN0
H'FFF5 IENR2 IENTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 MSTS4 MSTIIC MSTS3 MSTAD MSTWD MSTTW MSTTV MSTTA
H'FFFA MSTCR2 MSTS3_2 MSTTB3 MSTTB2 MSTTB1 MSTTX ⎯ MSTTZ0 MSTPWM
H8/3660
(Evalua-
tion chip)
H'FFFB MSTCR3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ MSTS4_2
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 LVDCR LVDE ⎯ ⎯ ⎯ LVDSEL LVDRE LVDDE LVDUE
H'F731 LVDSR ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ LVDDF LVDUF
H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 TXD2 ⎯ TXD ⎯
H'FFE1 PMR5 POF57 POF56 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0
H'FFE2 PMR3 ⎯ ⎯ ⎯ POF24 POF23 ⎯ ⎯ ⎯
H'FFF1 SYSCR2 SMSEL LSON DTON MA2 MA1 MA0 SA1 SA0
H'FFF2 IEGR1 NMIEG ⎯ ⎯ ⎯ IEG3 IEG2 IEG1 IEG0
H'FFF4 IENR1 IENDT ⎯ IENWP ⎯ IEN3 IEN2 IEN1 IEN0
H'FFF5 IENR2 ⎯ ⎯ IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 ⎯ ⎯ MSTS3 MSTAD MSTWD ⎯ MSTTV ⎯
H'FFFA MSTCR2 MSTS3_2 ⎯ ⎯ MSTTB1 ⎯ ⎯ MSTTZ MSTPWM
H8/36037
H8/36057
H'FFFB ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
