217
Table 8.47 Differences between the Evaluation Chip and the H8/36109 Registers
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F731 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F734 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F738 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F739 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F73A ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F73C ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F73D ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F73E ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F73F ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'FFEE PCRC PCRC7 PCRC6 PCRC5 PCRC4 PCRC3 PCRC2 PCRC1 PCRC0
H'FFEF ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF5 IENR2 IENTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF7 IRR2 IRRTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 MSTS4 MSTIIC MSTS3 MSTAD MSTWD MSTTW MSTTV MSTTA
H'FFFA MSTCR2 MSTS3_2 MSTTB3 MSTTB2 MSTTB1 MSTTX ⎯ MSTTZ MSTPWM
H'FFFB MSTCR3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ MSTS4_2
H8/3660
(Evalua-
tion chip)
H'FFFC TSCR ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ IICRST IICX
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 LVDCR LVDE BGRE ⎯ ⎯ LVDSEL LVDRE LVDDE LVDUE
H'F731 LVDSR ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ LVDDF LVDUF
H'F734 CKCSR PMRJ1 PMRJ0 ⎯ OSCSEL CKSWIE CKSWIF ⎯ CKCSTA
H'F738 RCCR RCSTP FSEL VCLSEL ⎯ ⎯ ⎯ RCPSC1 RCPSC0
H'F739 RCTRMDPR WRI PRWE LOCKDW TRMDRWE ⎯ ⎯ ⎯ ⎯
H'F73A RCTRMDR TRMD7 TRMD6 TRMD5 TRMD4 TRMD3 TRMD2 TRMD1 TRMD0
H'F73C ICRA ICRA7 ICRA6 ICRA5 ICRA4 ICRA3 ICRA2 ICRA1 ICRA0
H'F73D ICRB ⎯ ICRB6 ICRB5 ICRB4 ⎯ ⎯ ⎯ ⎯
H'F73E ICRC ICRC7 ⎯ ⎯ ICRC4 ⎯ ICRC2 ICRC1 ICRC0
H'F73F ICRD ICRD7 ICRD6 ICRD5 ICRD4 ICRD3 ⎯ ⎯ ⎯
H'FFEE PCRC ⎯ ⎯ ⎯ ⎯ PCRC3 PCRC2 PCRC1 PCRC0
H'FFEF SYSCR3 STS3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF5 IENR2 ⎯ ⎯ IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF7 IRR2 ⎯ ⎯ IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 ⎯ MSTIIC MSTS3 ⎯ MSTWD ⎯ MSTTV MSTTA
H'FFFA MSTCR2 MSTS3_2 ⎯ ⎯ MSTTB1 ⎯ ⎯ ⎯ MSTPWM
H'FFFB ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H8/36109
H'FFFC ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
To Next Page
