222
Table 8.56 Differences between the Evaluation Chip and the H8/36064 Registers
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'F731 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 TXD2 PWM TXD TMOW
H'FFE1 PMR5 POF57 POF56 WKP5 WKP4 WKP3 WKP2 WKP1 WKP0
H'FFE2 PMR3 POF27 POF26 POF25 POF24 POF23 ⎯ ⎯ ⎯
H'FFE4 PCR1 PCR17 PCR16 PCR15 PCR14 PCR13 PCR12 PCR11 PCR10
H'FFE5 PCR2 PCR27 PCR26 PCR25 PCR24 PCR23 PCR22 PCR21 PCR20
H'FFEA PCR7 PCR77 PCR76 PCR75 PCR74 PCR73 PCR72 PCR71 PCR70
H'FFEB PCR8 PCR87 PCR86 PCR85 PCR84 PCR83 PCR82 PCR81 PCR80
H'FFF0 SYSCR1 SSBY STS2 STS1 STS0 NESEL ⎯ ⎯ ⎯
H'FFF1 SYSCR2 SMSEL LSON DTON MA2 MA1 MA0 SA1 SA0
H'FFF4 IENR1 IENDT IENTA IENWP ⎯ IEN3 IEN2 IEN1 IEN0
H'FFF5 IENR2 IENTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF6 IRR1 IRRDT IRRTA ⎯ ⎯ IRRI3 IRRI2 IRRI1 IRRI0
H'FFF7 IRR2 IRRTB3 IENTB2 IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 MSTS4 MSTIIC MSTS3 MSTAD MSTWD MSTTW MSTTV MSTTA
H'FFFA MSTCR2 MSTS3_2 MSTTB3 MSTTB2 MSTTB1 MSTTX ⎯ MSTTZ MSTPWM
H8/3660
(Evalua-
tion chip)
H'FFFB MSTCR3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ MSTS4_2
Address Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
H'F730 LVDCR LVDE ⎯ ⎯ ⎯ LVDSEL LVDRE LVDDE LVDUE
H'F731 LVDSR ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ LVDDF LVDUF
H'FFE0 PMR1 IRQ3 IRQ2 IRQ1 IRQ0 TXD2 PWM TXD TMOW
H'FFE1 PMR5 ⎯ ⎯ WKP5 WKP4 WKP3 WKP2 WKP1 WKP0
H'FFE2 PMR3 ⎯ ⎯ ⎯ POF24 POF23 ⎯ ⎯ ⎯
H'FFE4 PCR1 PCR17 PCR16 PCR15 PCR14 ⎯ PCR12 PCR11 PCR10
H'FFE5 PCR2 ⎯ ⎯ ⎯ PCR24 PCR23 PCR22 PCR21 PCR20
H'FFEA PCR7 ⎯ PCR76 PCR75 PCR74 ⎯ PCR72 PCR71 PCR70
H'FFEB PCR8 PCR87 PCR86 PCR85 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF0 SYSCR1 SSBY STS2 STS1 STS0 ⎯ ⎯ ⎯ ⎯
H'FFF1 SYSCR2 SMSEL ⎯ DTON MA2 MA1 MA0 ⎯ ⎯
H'FFF4 IENR1 IENDT ⎯ IENWP ⎯ IEN3 IEN2 IEN1 IEN0
H'FFF5 IENR2 ⎯ ⎯ IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF6 IRR1 IRRDT ⎯ ⎯ ⎯ IRRI3 IRRI2 IRRI1 IRRI0
H'FFF7 IRR2 ⎯ ⎯ IENTB1 ⎯ ⎯ ⎯ ⎯ ⎯
H'FFF9 MSTCR1 ⎯ MSTIIC MSTS3 MSTAD MSTWD ⎯ MSTTV ⎯
H'FFFA MSTCR2 MSTS3_2 ⎯ ⎯ MSTTB1 ⎯ ⎯ MSTTZ MSTPWM
H8/36064
H'FFFB MSTCR3 ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
To Next Page
