224
(e) Although the hardware manual says that an initial value is 1, the compact emulator’s initial value is “0”.
These bits must always be set to 1, when counting up the watchdog timer.
Table 8.61 Differences between the H8/36094 Group Products (5)
Target Address Register Name Bits
H’FFC0 Timer Control/Status Register WD 2
(f) The H8/36094 group has power-on reset, optional low-voltage detection circuit functions and on-chip
oscillator. However, the E6000 emulator does not support these functions.
(g) The H8/36094 group has port C. However, the E6000 emulator does not support these functions.
To Next Page
