46
Source Address column
When a program is downloaded, an address for the current source file is displayed on the Source address column.
These addresses are helpful when setting the PC value or a breakpoint.
Event column
The Event column displays the following items:
: Address condition break by an event or a range channel
: Starts time measurement by an event channel
: Ends time measurement by an event channel
: Starts a point-to-point range trace
: Ends a point-to-point range trace
: Halts trace
These are also set by using the popup menu.
EXT.2 Trigger column
The EXT.2 Trigger column displays the following items:
: EXT.2-1 trigger condition
: EXT.2-2 trigger condition
: EXT.2-3 trigger condition
: EXT.2-4 trigger condition
: Two or more EXT.2 trigger conditions
It is also possible to set them by using the popup menu.
S/W Breakpoints column
This column displays the following items:
: A bookmark is set.
: A Software Break is set.
: PC location
