List of Video Input Signals Supported by the

Machine

This section describes input signals supported for each of the HDMI, DisplayPort, and VGA input

terminals.

Each input terminal supports input signals if they satisfy the following conditions:

The signal must comply with one of the following VESA standards:

• Industry Standards and Guidelines for Computer Display Monitor Timing (DMT) Standard-

Version 1 Revision 12

• Coordinated Video Timings (CVT) Standard Version 1.1

• Generalized Timing Formula (GTF) Version 1.1

The signal must also be one of those marked with a

symbol in the "HDMI Input" column,

"DisplayPort Input" column or "VGA Input" column of the following table:

Signal format Resolution

Frequency

(Hz)

HDMI Input

DisplayPort

Input

VGA Input

VESA CVT 1024 × 768 60 -

VESA GTF 1024 × 768 60 -

VESA DMT 1024 × 768 60 -

VESA GTF 1024 × 768 70 -

VESA DMT 1024 × 768 70 -

VESA CVT 1024 × 768 75 -

VESA DMT 1024 × 768 75 -

VESA CVT 1024 × 768 85 -

VESA DMT 1024 × 768 85 -

VESA CVT 1152 × 864 60 -

VESA GTF 1152 × 864 60 -

VESA CVT 1152 × 864 75 -

VESA GTF 1152 × 864 75 -

VESA DMT 1152 × 864 75 -

10. Appendix

316
