Procedure complete.
Procedure A
1. Remove the ADF [A], machine rear cover, scanner left cover, and scanner rear cover.
2. Measure the height difference [B] between the hinge bracket [C] and scanner housing [D].
3. If the difference is 0.5 mm or more:
