Ricoh OR-C1 User Manual

Jam Code
SP
Display Description
LCD
Display
7-504-206
FIN Registration Motor
(D586)
Paper position slide HP sensor does not turn
on after the paper position sensor slide motor
has turned off.
Paper position slide HP sensor does not turn
off after the paper position sensor slide motor
has turned on.
R1-R2
7-504-230 Fin Exit Paper exit sensor does not detect paper. R1-R2
7-504-231 Insufficient Data Data is Insufficient. R1-R2
Paper Size Code
Size Code Paper Size Size Code Paper Size
05 A4 LEF 141 B4 SEF
06 A5 LEF 142 B5 SEF
14 B5 LEF 160 DLT SEF
38 LT LEF 164 LG SEF
44 HLT LEF 166 LT SEF
132 A3 SEF 172 HLT SEF
133 A4 SEF 255 Others
134 A5 SEF - -
6. Troubleshooting
342
6
