Item EM 120K 240K 360K NOTE
APS Sensor C C C Dry cloth or blower brush
Around the Drum
Transfer/Separation Unit R R R
ID Sensor C C C
Perform the ID sensor initial setting
(SP2-935) after cleaning (blower
brush)
PCU
Drum R R R
Do SP2801. This initializes the
developer and resets the TD and
ID sensor outputs to their defaults.
It also resets the PCU counter.
Charge Roller R R R
Cleaning Roller R R R
Cleaning Blade R R R
Pick-off Pawls R R R
Developer R R R
Paper Feed
Registration Rollers C C C C Clean with water
Paper Feed Roller C C C C Dry cloth
Separation Roller C C C C Dry cloth
Pick-up Roller C C C C Dry cloth
Paper Feed Guides C C C C Clean with alcohol.
Relay Rollers C C C C Clean with water.
Dust collection box C C C C Remove, empty, clean
Fusing Unit and Paper Exit
Fusing Entrance and Exit
Guide Plates
C C C Clean with water or alcohol.
2. Appendix: PM Tables
38
