Only when installing this unit for use with Booklet Finisher (D589)
Replace the extension tray [A] with the wide extension tray [B] in the accessories of this unit only when
Booklet Finisher (D589) is attached to the machine.
Installation Procedure
1. Open the right cover [A].
2.
Remove the front right cover [B] ( x 1).
3.
Remove the inner tray [C].
4.
Remove the connector cover [D] ( x 1).
Bridge Unit BU3050 (D584)
75
