1. Create a folder, just as you would create a normal folder, in a location of your choice on
the computer.
2. Right-click the folder, and then click [Properties].
3. On the [Sharing] tab, click [Advanced Sharing...].
4. Select the [Share this folder] check box.
5. Click [Permissions].
6. In the [Group or user names:] list, select "Everyone", and then click [Remove].
7. Click [Add...].
8. In the [Select Users, Computers, Service Accounts, or Groups] window, click
[Advanced...].
9. Specify one or more object types, select a location, and then click [Find Now].
10. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
11. In the [Select Users, Computers, Service Accounts, or Groups] window, click [OK].
12. In the [Group or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Change] check box.
Configure the access permissions for each group and user.
13. Click [OK].
Step 3: Specifying access privileges for the created shared folder
If you want to specify access privileges for the created folder to allow other users or groups to access
the folder, configure the folder as follows:
1. Right-click the folder created in Step 2, and then click [Properties].
2. On the [Security] tab, click [Edit...].
3. Click [Add...].
4. In the [Select Users, Computers, Service Accounts, or Groups] window, click
[Advanced...].
5. Specify one or more object types, select a location, and then click [Find Now].
6. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
7. In the [Select Users, Computers, Service Accounts, or Groups] window, click [OK].
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Modify] check box.
9. Click [OK].
5. Scan
136

Table of Contents

Other manuals for Ricoh Pro C5200s

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Pro C5200s and is the answer not in the manual?

Ricoh Pro C5200s Specifications

General IconGeneral
Print TechnologyLaser
Max Paper Size330.2 x 487.7 mm
Monthly Duty Cycle300, 000 pages
Print Speed65 ppm
Resolution1200 x 4800 dpi
Paper Input Capacity8, 250 sheets
Paper Weight52 to 360 gsm
Duplex PrintingStandard
Network ConnectivityEthernet 10Base-T/100Base-TX/1000Base-T
Supported Media SizesA3, A4, A5, B4, B5
Supported Media TypesPlain, Recycled, Coated, Envelope
Warm-up TimeLess than 5 minutes
