4. [Prt. From Dev.]
Press to display the screen for directly printing files stored on memory storage devices.
5.
[Job Reset]
Press to cancel the current print job.
If you press it when Hex Dump is selected, Hex Dump is canceled.
6. [Job Operation]
Press to suspend a job being processed.
7. [Form Feed]
Press to print all the data left in the printer's input buffer.
8. [Other Functns.]
Press to display the error logs and status of spooled jobs.
Using the [Information] screen
This function is available for SP 4520DN only.
To raise environmental awareness, you can configure the printer to show users the amount of paper
saved by using the various paper saving functions of the printer.
When user authentication is enabled, the screen is displayed when you log in to the printer. When user
authentication is not enabled, the screen is displayed after the printer returns from Sleep mode or after a
system reset. The [Information] screen appears when the power is turned on, regardless of the
authentication settings.
1. Message
Displays messages from the administrator.
2.
Total Print Pages
Displays the total numbers of pages printed in the current and previous count periods.
3. Eco-friendly Indicator
• Paper Reduction:
1. Getting Started
24
