Write Bar Code Control
Bar Code Area Position
Offset Range Meaning Error Code
0-1 X'000B'-
X'xxxx'
LENGTH of Bar Code Area Position (BCAP) X'0202..0
5'
2-3 X'AC6B' STRUCTURED FIELD ID X'020B..
05'
4-5 X'8000'-
X'7FFF'
Bar Code BLOCK ORIGIN Xp, I, or IOFFSET coordinate
position (in 1440ths)
X'0411..0
0'
6-7 X'8000'-
X'7FFF'
Bar Code BLOCK ORIGIN Yp, B, or B-OFFSET coordinate
position (in 1440ths)
X'0411..0
0'
8-9 ORIENTATION OF Bar Code BLOCK X'0203..0
5'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
10 COORDINATE REFERENCE SYSTEM X'0204..0
5'
X'00' Absolute I, Absolute B
X'20' Absolute I, Relative B
X'40' Relative I, Absolute B
X'60' Relative I, Relative B
X'A0' Page Xp, Yp
11-n :c Ignored
6. Bar Code Command Set
172
