Offset Range Meaning Error Code
8-9 ORIENTATION OF IMAGE BLOCK X'0203..0
5'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
10 COORDINATE REFERENCE SYSTEM X'0204..0
5'
X'00' Absolute I, absolute B
X'20' Absolute I, relative B
X'40' Relative I, absolute B
X'60' Relative I, relative B
X'A0' Page Xp, Yp
11-n Ignored
Image Output Control
This data structured field specifies the mapping option for the image object. It is an ELECTIVE data field
in the Write Image Control 2 command. If this field is omitted, the printer will use the following default
values:
Mapping option = X'30' (Position and Trim)
X, Y Offset = 0.
X, Y Extent = Image Presentation Space extent defined by the Image Data Descriptor structured field.
Offset Range Meaning Error Code
0-1 X'0010' -
X'xxxx'
LENGTH of Image Output Control X'0202..0
5'
2-3 X'A66B' Structured Field ID X'020B..
05'
IO Image Commands
137
