Offset Range Meaning Error Code
2 MEDIA ORIGIN X'026F..
02'
X'00' Top-left corner
X'01' Top-right corner
(Bottom-left corner if back side of duplex sheet)
X'02' Bottom-right corner
X'03' Bottom-left corner
(Top-right corner if back side of duplex sheet)
XOH Set Media Size
This order specifies SIZE of the physical medium.
Offset Range Meaning Error Code
0-1 X'1700' Set Media Size (SMS) order code
2 UNIT BASE (Measurement Units) X'0274..0
2'
X'00' 10 in.
X'01' 10 centimeters
3-4 L-Units per UNIT BASE X'0270..0
2'
X'3840' 14400 L-Units/10 inches
X'1626' 5670 L-Units/10 centimeters
X'0960' 2400 L-Units/10 inches
X'03B1' 945 L-Units/10 centimeters
5-6 X'0001' -
X'7FFF'
Xm EXTENT of MEDIUM
See "Notation Conventions", IPDS Technical Reference 1.
X'0272..0
2'
X'FFFF' Printer Default (Printer's control panel setting or Tray sensors)
Execute Order Home State (XOH)
101
